In a recent discussion among ControlUp community members, the capability of passing output from the "Run System Command" node directly into the next step of a workflow was explored. The specific use case involved reading a device’s Organizational Unit (OU) from Active Directory (AD) and using that information to dynamically assign tags through the "Update Tags" node in a workflow. The question centered on whether the result of a command or script executed by the "Run System Command" node could be piped directly to the subsequent node for immediate processing.
The response clarified that currently, ControlUp's "Run System Command" or script execution nodes do not support the direct output transfer or piping of command results into subsequent workflow steps. This limitation means that you cannot directly feed command or script output into another node like "Update Tags" within the same workflow step sequence.
A recommended workaround involves using a data index alongside a script. The script, executed by the "Run System Command" node, can write the needed output (such as device OU information) to a ControlUp data index. The "Update Tags" node or any subsequent workflow step can then query and apply data from this index, thereby indirectly passing the information through the workflow with a slight delay compared to direct piping. Another mentioned option involves invoking a new flow via a REST API call from the script once execution completes, which offers a programmatic way to chain operations but also introduces additional complexity.
While there is no current timeline for enabling direct output passing from the "Run System Command" node, the ControlUp team acknowledged the usefulness of this feature and indicated plans to add it in the future to streamline workflows by eliminating the need for external data storage steps or additional scripts.
For further guidance on automating tags based on device attributes, workflows, and data indexing in ControlUp, users may refer to the official ControlUp documentation at https://docs.controlup.com and the ControlUp Academy at https://cuacademy.controlup.com, where detailed instructions and best practices for workflow automation and integrating Active Directory data can be found.
Read the entire article here...
Scripts Related Training & Support Archives
Scripts training and support-related archives from inside the ControlUp Community on Slack.
How to Fix 400 Errors Caused by Using _id Sorting in ControlUp Edge API Queries
A PowerShell script that queries device data from the ControlUp Edge API using paginated search_after calls experienced failures starting Sunday, returning a 400 Bad Request error. The error message indicated that sorting or aggregations on the _id metadata field were no longer supported, specifically stating that "Using the _id metadata field in aggregations, sorts, scripts, or top-level field loads... is not supported because it loads fielddata into the heap." This change caused calls sorting by the internal OpenSearch/Elasticsearch document _id to fail.
The root cause was an upstream change implemented over the weekend by ControlUp. The API now blocks the use of the _id metadata field in queries to prevent severe OpenSearch JVM issues such as Out of Memory (OOM) conditions, which were observed when sorting or aggregating on large indexes by _id. This protective measure was applied after discovering more widespread usage of _id sorting than previously expected. In response to the problem and customer impact, ControlUp temporarily disabled this restriction for affected tenants, including the user’s tenant, to restore functionality while addressing the underlying stability concerns.
The resolution for the user’s scripts was to update their pagination logic to sort and search_after using a real mapped field, such as device name, instead of the internal _id metadata field. This change immediately restored proper API operation without requiring further modifications. The user’s initial script had been generated with assistance from a language model but required this adjustment due to the updated API behavior.
The discussion also raised the topic of API change notifications. ControlUp has yet to provide advance announcements or subscription-based alerts for breaking API changes, which users expressed interest in receiving. ControlUp may consider this feedback to improve communication about future updates.
For users facing similar errors, it is essential to avoid using the internal _id metadata field for sorting or pagination in ControlUp API queries. Instead, rely on indexed, mapped fields to ensure compatibility with recent security and stability improvements to the ControlUp Edge API backend built on OpenSearch.
Relevant ControlUp resources include the official documentation on the Edge API and pagination techniques, available at https://docs.controlup.com, and the ControlUp Academy at https://cuacademy.controlup.com for learning best practices with API integration.
Read the entire article here...
Read the entire article here...
How to Update Device Registration Codes for Existing ControlUp Agents After Code Expiration
ControlUp has deprecated the old Device Registration Codes across all tenants, requiring a transition to new codes for agent deployment. While new agent installations using the latest Device Registration Code proceed without issues, existing devices that were registered prior to the code expiration retain the old registration code in the Windows registry. This persistence causes a problem when these devices become inactive and are removed from ControlUp. Upon attempting to re-register, the ControlUp Agent reads the outdated, expired Device Registration Code from the registry, which leads to a registration failure.
The recommended approach to resolve this for existing devices differs from the process for new installations. The latest Agent Manager deployment automatically uses the new Device Registration Code for fresh agent installs; however, it does not automatically update the registration code already stored in the registry of existing agents. Therefore, device re-registration fails if the persisted old code is expired. There is no official migration tool provided by ControlUp to update this registry value across existing installations en masse. The key registry path involved is `HKLM\SOFTWARE\Avacee\SIP` and the relevant value is `DeviceRegistrationCode`.
For an immediate workaround, ControlUp acknowledges that updating the registry manually or via script on affected devices is effective. This involves stopping the SIP Agent service, updating the `DeviceRegistrationCode` registry value to the current valid code, and restarting the service. Given that agent version auto-updates are managed separately (either by ControlUp version control or via user-managed software deployment like SCCM or Intune), it is the administrator’s responsibility to ensure deployment tools push such remediation scripts or silent Agent Manager reinstalls outfitted with the new Device Registration Code to devices at scale.
In practice, many organizations use deployment platforms such as Intune or SCCM to run remediation scripts that overwrite the expired registration code in the registry of existing agent installations, thereby preventing registration failure without full reinstallation. This approach balances efficiency and scale, allowing smooth transition without requiring large-scale agent removal and fresh installation. Administrators should plan to deploy these registry updates proactively to avoid disruptions caused by automatic agent attempts to re-register post device inactivity cleanup.
For further details on Agent Manager deployment and registry settings, consult the ControlUp documentation at https://docs.controlup.com/.
Read the entire article here...
Read the entire article here...
ControlUp Community Meetup #17 — ControlUp AI: How It Works, Where It Helps, and What’s Coming
Our latest ControlUp Community Meetup recording is live. Shay Dezaldety breaks down the ControlUp AI Assistant: how it picks the right tools and data from your environment, how RBAC and approval gates keep admins in control, and a live demo troubleshooting poor digital experience, memory and Wi-Fi issues, and BSOD remediation. Copilot, not autopilot.
Read the entire article here...
Read the entire article here...
Managing ControlUp’s CoreAgent on macOS without a Bundle ID
ControlUp's C4Desktop for macOS utilizes the CoreAgent process to collect and transmit inventory data to the ControlUp platform. This agent is responsible for maintaining device registration, managing credentials, and facilitating communication between the device and ControlUp services. Additionally, CoreAgent oversees scheduled tasks such as periodic device reporting, license checks, and configuration updates. It also monitors and manages supporting modules that gather specific data, including CPU usage, Wi-Fi status, process information, crash reports, location data, and collaboration application activity. In the event that any of these supporting modules cease functioning, CoreAgent is designed to restart them to ensure continuous data collection. Furthermore, CoreAgent serves as the central hub for data transmission, securely uploading collected information to ControlUp and facilitating features like remote control and file browsing.
The CoreAgent binary is located at `/usr/local/com.controlup.edgedx.agent/Bin/CoreAgent` on macOS systems. It's important to note that CoreAgent is a signed binary and not an `.app` bundle, which means it does not have a `CFBundleIdentifier` and, consequently, lacks a bundle ID. This absence can present challenges when integrating with Mobile Device Management (MDM) solutions like Jamf, which typically rely on bundle IDs for application management. ControlUp does not publish a bundle ID for CoreAgent, and there is no documented `CFBundleIdentifier` for it in the Jamf or MDM documentation. Instead, for CU4Desktop on macOS, MDM profiles target other agent components by bundle ID. The main one tied to the core agent stack is:
This approach allows MDM solutions to manage and configure the necessary components of the ControlUp agent effectively, even in the absence of a bundle ID for CoreAgent itself. For detailed instructions on deploying ControlUp for Desktops with Jamf, including the creation of configuration profiles and deployment scripts, refer to the official ControlUp documentation. ([support.controlup.com](https://support.controlup.com/docs/deployment-with-jamf?utm_source=openai))
In summary, while CoreAgent is integral to the functionality of ControlUp's C4Desktop for macOS, its lack of a bundle ID requires alternative methods for management and deployment, particularly when using MDM solutions like Jamf. By targeting other agent components with known bundle IDs, organizations can effectively deploy and manage the ControlUp agent on macOS devices.
Read the entire article here...
Read the entire article here...
Troubleshooting FSLogix Profile Lock Event Triggers with ControlUp’s New Windows Event Log Monitoring in DEX
A common issue arises when configuring ControlUp triggers for FSLogix profile event handling, particularly with the new Windows Event Log Monitoring feature in ControlUp Digital Employee Experience (DEX). A user setting up a trigger based on FSLogix event ID 999 (ControlUp-FSLogixProfileLocked) noticed that although the event appeared in the local Windows event log, the associated trigger action (such as running a script on profile lock) did not execute. After enabling the new Windows Event handling and creating a corresponding filter for event 999 in the ControlUp web console, the event was correctly detected, and the action was attempted but failed with the error: "Script execution failed: CUTriggerObject is not available. This script must be run from a ControlUp trigger."
The root cause relates to how the new DEX Windows Event Log Monitoring selectively forwards events based on collection rules. By default, custom events like event 999 are not included in these rules and thus remain only in the local event log, preventing real-time triggers from detecting them. When such events are collected through DEX, the script execution context differs—in particular, the `$CUTriggerObject` scripting object (which provides event details like username and machine name) is not available in scripts run through DEX event filters. This causes the script failure because it expects this object to be populated.
The solution is to add a DEX rule that explicitly collects event 999 to allow monitoring and alerting, but continue using the imported Real-Time trigger for executing the FSLogix logoff script. This trigger runs in the correct context and has access to `$CUTriggerObject`, allowing the script to function as intended. The presence of the event in the web console and receiving email notifications after adding the DEX rule demonstrate that events are collected, but only the real-time trigger can correctly handle the associated script action. Also, users should verify their scripts have the "Execute with.NET engine" option enabled to ensure proper script execution.
This issue does not stem from permissions or account misconfiguration but from the distinct operational contexts between DEX event filtering and real-time triggers. For detailed guidance, users can consult the ControlUp blog article on fixing FSLogix profile attach issues at https://www.controlup.com/blog/how-to-fix-the-fslogix-issue-the-user-profile-failed-to-attach/. Additional troubleshooting tips and best practices for script and trigger setup can be found in the ControlUp Knowledge Base and Academy resources at https://docs.controlup.com and https://cuacademy.controlup.com respectively.
Read the entire article here...
Read the entire article here...
How to Update Records Without Duplication and Manage Retention in Custom ControlUp Edge Data Indexes
When writing records to a custom ControlUp Edge data index via the REST API (POST to edge/api/data/), users may encounter an issue where repeated writes of the same record result in duplicate entries rather than updates to existing records. Additionally, there is a desire to prevent these records from expiring after the default 28 days of inactivity. This discussion sheds light on both the mechanics of record updating and the association of records with the endpoint running the write operation.
The key to controlling whether a record is created anew or updated lies in the uniqueness of the "key" field or primary identifier used in the data index schema. When writing data via a PowerShell script—whether executed inside ControlUp or externally—the operation will create a new record if the key value is not recognized. To update an existing record, the key must remain consistent and the write must explicitly target that key. The official ControlUp scripting guide provides useful guidance for writing data to an index, outlining how to structure the payload and use keys: https://support.controlup.com/docs/scripting-guide#writing-to-a-data-index. Running the script inside ControlUp offers the advantage of on-demand execution with local file availability, but it is not strictly necessary; scripts can also run externally.
A practical complication arises from the fact that data written to the index often becomes associated with the endpoint where the script executes, as seen when the computer name appears linked to each record. This behavior stems from ControlUp’s design, where data sources are tied to machine endpoints to facilitate monitoring and troubleshooting. In scenarios where building information needs to be stored independently of endpoint context, some organizations have implemented custom solutions such as storing building data locally on endpoints (e.g., in registry or Active Directory properties), then running scripts on each endpoint to gather and send this data to ControlUp. While this approach inherently associates data with those endpoints, it maintains up-to-date building information across the environment.
Controlling record expiration beyond the default 28 days typically requires adjusting settings on the data index or implementing regular writes to keep the record active. Without ongoing updates, ControlUp’s retention policy will remove inactive records. Users are also encouraged to explore ControlUp Workflows for automating data collection and writing processes, which can streamline operations despite a learning curve. The ControlUp support team and community forums remain valuable resources for addressing specific scripting and data index challenges.
For additional details and sample scripts, the ControlUp scripting guide is recommended: https://support.controlup.com/docs/scripting-guide#writing-to-a-data-index.
Read the entire article here...
Read the entire article here...
Support for Boolean Fields in ControlUp Indexes via PowerShell Scripts
A community member inquired about the official support for Boolean columns in ControlUp when written to via a PowerShell script. They noted that their script was functioning as expected, showing a dropdown with options for "true" and "false" instead of a plain text box for the Boolean field. This behavior indicates that Boolean fields are recognized and handled appropriately within the ControlUp system's indexing and UI.
The confirmation came from multiple users, including a ControlUp expert, that Boolean fields are indeed supported. ControlUp's platform supports defining columns with Boolean data types, enabling users to interact with these fields through dropdown selectors for true/false values, which enhances data consistency and ease of use.
This means that scripts or automation workflows that write Boolean values into ControlUp indexes can rely on native support for true/false states. This feature is useful for scenarios where binary states need to be tracked and toggled directly from the ControlUp interface without requiring manual text input.
For more detailed information on supported data types and scripting integration with ControlUp indexes, users can refer to the official ControlUp documentation at https://docs.controlup.com, and consider the ControlUp Academy (https://cuacademy.controlup.com) for deeper learning resources on scripting and data management in ControlUp.
Read the entire article here...
Read the entire article here...
How to Identify and Manage Duplicate Devices in ControlUp Desktops Due to Reimaging and Agent Re-registration
A common challenge with ControlUp's Desktops product arises when IT teams test new device models by repeatedly reimaging machines, causing multiple instances of the same device to register with unique device IDs but identical hostnames. This scenario leads to an inflated license count, as each registration consumes a license until the devices are flagged inactive and subsequently removed from the system.
To identify these "duplicate" devices, one effective method involves querying the ControlUp `device_status` data index. While leveraging ControlUp Dashboards can help visualize this data, caution is advised when running queries based solely on device IDs without applying appropriate filters to avoid misleading results. Advanced options in the dashboard allow adding additional metrics that can pinpoint such duplicates by hostname or device name, which is particularly helpful since the root issue is not duplicate device IDs but duplicate device names retained after reimaging.
In practice, customizing dashboard widgets with additional filters and metrics can enable teams to monitor and isolate devices that have been repeatedly reimaged and registered, streamlining license management. For devices already deployed, it is possible to run a script that forces re-registration of devices with a new unique ID to prevent license count inflation. This step may be beneficial where device IDs need to be refreshed or reset in the ControlUp environment.
Another important factor involves deployment parameters. For example, the `REGISTERWITHNAME=1` flag, if set during agent deployment, can cause devices to register under the same name, exacerbating duplicate name issues. However, in many cases, the default setting with the `ALLUSERS=1` flag, used in ControlUp's standard installer from the Downloads pane, is sufficient and does not trigger duplicate registrations unless devices are repeatedly reimaged and reset by users.
Overall, the underlying cause of the inflated license usage is the repeated device reimaging and agent re-registration under the same hostname but with unique IDs. Proper use of the `device_status` index for querying, cautious dashboard configurations, potential scripting to reset device IDs, and awareness of deployment flags can effectively manage and mitigate "duplicate" device issues within the ControlUp Desktops product.
Read the entire article here...
Read the entire article here...
Enabling FSLogix Metrics on ControlUp Dashboards Using Real-Time Data and Upcoming API Enhancements
ControlUp users have inquired about displaying FSLogix metrics on the ControlUp Dashboard, but encountered the limitation that no predefined FSLogix metrics are currently available in the existing data scopes. This is because FSLogix real-time data is not currently included in ControlUp’s historical data sets, which underpin the dashboard's metric options and the public API. As a result, FSLogix metrics are not accessible through these channels at present.
ControlUp’s product management and development teams have confirmed that this situation is expected to change soon. There is an upcoming Real-time public API planned for release that will include FSLogix real-time data. This update will enable users to access FSLogix metrics on dashboards in real time, expanding the ability to monitor FSLogix environments directly within the ControlUp interface.
In parallel, ControlUp is also working on extending real-time data access for its AI Assistant functionality. Once implemented, this will allow users to generate dynamic visuals and analyses on FSLogix data using the AI Assistant, further enhancing real-time monitoring and troubleshooting capabilities related to FSLogix.
For now, users cannot directly add FSLogix metrics to dashboards due to the absence of these metrics in the historical data and public API. However, the forthcoming updates will bridge this gap, allowing seamless integration of FSLogix metrics into ControlUp’s real-time dashboards and AI-driven analytics. For further information on ControlUp dashboards and the evolving capabilities, users can refer to the official documentation at https://docs.controlup.com and the ControlUp Academy at https://cuacademy.controlup.com.
Read the entire article here...
Read the entire article here...
